Magnetic Products MP015290 6? ?18? Rare Earth Surface Grinder Chuck 100N/cm2 holding force SGC-150450-REN
Short Description
Magnetic Products 6″ x 18″ Rare Earth Surface Grinder Chuck 100N/cm2 holding force MP015290
Full Description
Shape
Rectangular
Height
2″
Magnetic Type
Permanent
Pole Type
Transverse
Length
18″
Pole Spacing
T1.9 1.4+0.5 mm
Width
6″
• Dual neodymium (Rare Earth) magnetic system: nominal holding force: 100 N/cm2 – 145lbs/in². • Min. workpiece size: 4 × 4 × 1 mm – .157 x .157 x .039 in. • Regrinding limit: 7 mm – .275 in. • Ideal for precise grinding of small and thin pieces, can also be used for large pieces. • Waterproof can be used with coolant or immersed in dielectric liquid (EDM applications). • The upper top plate composed of brass and steel lamellae ensures high stability, accuracy, and efficiency of clamping. • One (1) year warranty for the magnetic system.
