KIPP K0317.1AE SPRING PLUNGER LIGHT SPRING FORCE D=8-32 L=15, STEEL, COMP:PIN STEEL, PU=25 Discount

Original price was: $4.94.Current price is: $1.98.

SKU: US-8765593551053 Categories: , Tag:

Description

KIPP K0317.1AE SPRING PLUNGER LIGHT SPRING FORCE D=8-32 L=15, STEEL, COMP:PIN STEEL, PU=25
KIPP K0317.1AE SPRING PLUNGER LIGHT SPRING FORCE D=8-32 L=15, STEEL, COMP:PIN STEEL, PU=25
Spring Plungers pin style, hexagon socket, steel pin, light end pressure, inch
Material: Body steel quality class 5.8. Thrust pin steel. Spring Class D steel wire. Type: Black oxide finish. Thrust pin hardened. Part Number Example: K0317.AD Note: For the inch series, dimension D and S are in inches, all other dimensions are in mm. Drawing reference: 1) grub screw glued in

Main Material: Steel
Item: Spring Plunger
Rohs: Yes
Packaging Unit: 25
D: 8-32
D1: 1.5
Spring Strength: Light
Spring Force Initial Pressure F1 Approx. N: 2
Spring Force Final Pressure F2 Approx. N: 7
H: 1.5
L: 15
N: 0.6
S: 0.05
T: 2
T1: 0.6
